How to deploy on Sunbeam
Duration : Up to 60 minutes depending on internet download speed.
This guide goes through the steps for setting up Sunbeam and deploying Charmed MySQL.
Prerequisites
- A physical or virtual machine running Ubuntu 22.04+
- If you’d like to follow this guide in an isolated test environment, you can launch a Multipass instance.
- Hardware requirements depend on planned deployment size.
- Recommended: 8 CPU cores, 32GB RAM, 100GB of storage
- Minimum: See the requirements listed in the Sunbeam documentation
Steps
- Install and bootstrap Sunbeam
- Enable OpenStack Images Auto-sync
- Set up Juju inside an OpenStack bastion
- Deploy Charmed MySQL
- (Optional) Access the OpenStack dashboard
Install and bootstrap Sunbeam
Follow the official OpenStack guide: Single-node deployment.
Pay attention to the Caution and Note sections - the /etc/hosts will require a manual fqdn fix.
Enable OpenStack Images Auto-sync
Follow the official Images Sync guide to enable auto-sync and wait for the image 22.04 to be downloaded.
Set up Juju inside an OpenStack bastion
Follow the MicroStack guide Manage workloads with Juju from the beginning, and stop after the section “Create a Juju controller”.
To summarize, the relevant sections are:
- Set up the bastion
- Install and configure the Juju client
- Create a Juju controller
Deploy Charmed MySQL
Add a model if you don’t have one already, and deploy a MySQL cluster. Use the -n flag to specify number of units.
juju add-model mysql
juju deploy mysql --base ubuntu@22.04 -n 3
Sample output of juju status --watch 1s:
Model Controller Cloud/Region Version SLA Timestamp
mysql my-controller sunbeam/RegionOne 3.5.4 unsupported 20:22:42Z
App Version Status Scale Charm Channel Rev Exposed Message
mysql 8.0.36 active 3 mysql 8.0/stable 240 no
Unit Workload Agent Machine Public address Ports Message
mysql/0* active idle 0 192.168.122.211 3306,33060/tcp Primary
mysql/1 active idle 1 192.168.122.226 3306,33060/tcp
mysql/2 active idle 2 192.168.122.14 3306,33060/tcp
Machine State Address Inst id Base AZ Message
0 started 192.168.122.211 3f0a331c-bc08-4bae-af22-44087a7b74d6 ubuntu@22.04 nova ACTIVE
1 started 192.168.122.226 e6e908f8-0da1-4440-9bbd-9f1c1bc780df ubuntu@22.04 nova ACTIVE
2 started 192.168.122.14 6f9ad7cd-2a9d-435e-a6d8-3e39bf2218cd ubuntu@22.04 nova ACTIVE
(Optional) Access the OpenStack dashboard
Follow the official guide: Accessing the OpenStack dashboard.
When using a Multipass VM, you may need to manually route OpenStack IPs. For example:
sudo ip route add 10.10.10.0/24 via 10.76.203.210
where 10.76.203.210 is the IP of the Multipass VM and 10.10.10.0 is the network returned by sunbeam dashboard-url.
The image below is an example of the OpenStack dashboard view (bastion + juju controller + 3 mysql nodes):
To learn more about deploying and operating MySQL, see the Charmed MySQL tutorial.
